Victron Blue Smart IP65 12/15 Battery Charger: Your Reliable Charging Solution


The Victron Blue Smart IP65 12/15 Battery Charger is a versatile and advanced charging solution designed to meet the needs of various users, from automotive enthusiasts to marine and industrial professionals. This high-performance charger combines cutting-edge technology with user-friendly features, ensuring your batteries are charged efficiently and safely.


Key Features:

Efficient Charging: Engineered for maximum efficiency, the Victron Blue Smart IP65 12/15 operates at up to 94% efficiency, ensuring less energy is wasted as heat, leading to cooler operation and longer-lasting performance.

Seven-Stage Adaptive Charging: The charger utilises a sophisticated seven-stage charging algorithm, optimising each cycle. The stages—Test, Bulk, Absorption, Recondition, Float, Storage, and Refresh—ensure your battery is charged optimally and maintained in top condition.

Bluetooth Smart Technology: With built-in Bluetooth, you can monitor and control the charging process remotely via the VictronConnect app. This feature offers convenience and flexibility, allowing you to keep track of your battery’s status from your smartphone or tablet.

Durable and Weatherproof: The IP65 rating ensures the charger is dust-tight and protected against water ingress, making it ideal for use in harsh environments such as workshops, garages, and marine settings.

Temperature Compensation: Automatically adjusts the charging voltage based on the ambient temperature, providing optimal charging performance in both hot and cold climates.

Reconditioning Mode: Designed to revive deeply discharged batteries, this mode applies a higher voltage during the absorption phase. It can significantly extend the life of your batteries by preventing sulfation, a common issue in lead-acid batteries.

Low Current Mode: Reduces the maximum charge current, making it suitable for charging smaller batteries without risking damage.

Silent Operation: Operates silently, thanks to its fanless design, making it ideal for use in noise-sensitive environments or for overnight charging.

Technical Specifications:

Input Voltage Range: 180-265V AC, 45-65Hz
Output Voltage: 12V
Charge Current: 15A (Normal mode), 4A (Low current mode)
Efficiency: Up to 94%
Protection Category: IP65 (dust-tight and protected against water ingress)
Operating Temperature: -40°C to +60°C (full rated output up to 30°C)
Dimensions: 60 x 105 x 190mm
Weight: 0.9 kg
Battery Types Supported: Lead-acid (AGM, GEL, Calcium), LiFePO4
Charge Algorithm: Seven-stage adaptive with optional recondition mode
Bluetooth Connectivity: Yes, via VictronConnect app
Certifications: EN 60335-1, EN 60335-2-29, EN 55014-1, EN 61000-6-3, EN 61000-3-2

Installation and Setup:

Setting up the Victron Blue Smart IP65 12/15 Battery Charger is straightforward:

Unpack the Charger: Ensure all components are present, including the charger unit, DC cables, and AC power cord.
Connect the DC Cables:  Start by connecting the red and black DC cables to the charger, then the battery terminals. Ensure the connections are secure and that the terminals are clean to avoid any potential issues.

Connect to AC Power: Plug the AC power cord into a mains outlet. The charger will automatically power on, and the LEDs will indicate its current status.

Select the Charging Mode: Use the MODE button to cycle through the available charge modes (Normal, High, or Li-ion) until the desired mode is selected.

Monitor Charging via Bluetooth: Download the VictronConnect app on your smartphone or tablet to monitor and control the charging process remotely. The app provides detailed insights into the charging status, allowing adjustments and firmware updates.

Charging Cycle: The charger will automatically progress through the charging stages, with real-time feedback provided by the LEDs and the VictronConnect app.

Completion and Float Mode: Once the battery is fully charged, the charger will enter Float mode, maintaining the battery at 100% charge. This is the ideal time to disconnect the charger, though it can also be left connected to maintain the battery if not in use.

Maintenance Charging: If the battery will be idle for an extended period, the charger’s Storage mode will help maintain the battery's health by preventing sulfation, ensuring it remains in good condition for future use.


The Victron Blue Smart IP65 12/15 Battery Charger is a reliable and versatile charging solution for anyone needing to maintain 12V batteries in optimal condition. Whether you're charging a car battery, a boat battery, or a battery used in industrial equipment, the Blue Smart IP65 12/15 offers the advanced features and robust design needed to ensure your batteries are always ready for use. With its high efficiency, intelligent charging algorithm, and durable construction, this charger is an excellent choice for those who require a dependable charging solution that can perform in a variety of environments. Make the smart choice with the Victron Blue Smart IP65 12/15 Battery Charger, and enjoy the peace of mind that comes with knowing your batteries are in good hands.
