The Victron Energy SmartSolar Charge Controller MPPT 100/30 is a cutting-edge device designed to maximise the efficiency of solar panel systems. It employs Maximum Power Point Tracking (MPPT) technology that enhances solar harvest, especially under cloudy skies, improving energy intake by up to 30% compared to PWM controllers. This model is tailored for both 12V and 24V systems and supports up to 440W and 880W of PV power respectively, with a robust charge current of 30A.

Technical Specifications:

  • Battery Voltage: Auto selection between 12V and 24V systems.
  • Maximum PV Open Circuit Voltage: 100V, allowing for a range of solar panel configurations.
  • Charge Current Capacity: Up to 30A, designed to handle substantial power needs efficiently.
  • Maximum Efficiency: Achieves up to 98%, ensuring minimal energy loss and optimal performance.

Advanced Features:

  • Bluetooth Smart Integration: Offers the convenience of wireless setup, monitoring, and updates via the VictronConnect app.
  • Flexible Charge Algorithm: The charge controller is programmable with eight pre-programmed algorithms selectable via a rotary switch, catering to various battery types and charging requirements.
  • Safety Protections: Equipped with extensive electronic protections including over-temperature protection, PV short circuit, and reverse polarity protection, ensuring system safety and longevity.
  • Temperature Compensation: Features an internal temperature sensor that adjusts charge voltage based on temperature changes, optimising battery life.

Design and Build:

  • Compact Dimensions: Measures 130 x 186 x 70 mm, making installation easy in various settings.
  • Lightweight: Weighs approximately 1.3 kg, enhancing portability and ease of handling.
  • Environmental Durability: Rated IP43 for electronic components, ensuring protection against environmental elements.

The SmartSolar MPPT 100/30 is ideal for medium-sized solar systems used in residential, RV, marine, and off-grid applications. Its ability to adapt to various voltages and its high efficiency make it particularly effective in geographic areas with inconsistent sunlight. With the addition of user-friendly Bluetooth connectivity and robust safety features, it stands out as a reliable and efficient solution for managing solar energy. This charge controller is not just about energy efficiency; it also focuses on ease of use and safety, making it a comprehensive solution for sustainable energy management.

MPPT Solar Calculator

Data Sheet

Controller TypeMPPT
BluetoothNo
Warranty60
Model # SCC020030200
Barcode # 08719076025542

Be The First To Review This Product!

Help other Archer Batteries Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

What does MPPT stand for?
MPPT stands for Maximum Power Point Tracking, a technology that maximises the efficiency of the solar panel's energy conversion.
What is the maximum PV open circuit voltage for the MPPT 100/30?
The MPPT 100/30 can handle up to 100 volts of open circuit voltage from solar panels.
Can the MPPT 100/30 be used for both 12V and 24V systems?
Yes, it automatically detects and works with both 12V and 24V battery systems.
What is the maximum charge current of the MPPT 100/30?
The charge controller has a maximum output of 30 amps.
Does the MPPT 100/30 come with Bluetooth connectivity?
Yes, it includes Bluetooth Smart for wireless monitoring and configuration via the VictronConnect app.
Can I program the charge algorithm on the MPPT 100/30?
Yes, it features a fully programmable charge algorithm and also includes eight pre-programmed algorithms selectable with a rotary switch.
What kind of protections does the MPPT 100/30 offer?
It includes over-temperature protection, PV short circuit protection, and PV reverse polarity protection.
What is the efficiency rate of the MPPT 100/30?
It boasts a peak efficiency of 98%.
How can I monitor the performance of my MPPT 100/30?
Performance can be monitored via the VictronConnect app, which provides real-time insights and historical data.
