VoltGo VLRV2560A Lithium Iron Phosphate Battery: Power, Performance, and Peace of Mind for All Your Energy Needs
The VoltGo VLRV2560A Lithium Iron Phosphate (LFP) Battery is designed to be the cornerstone of your energy storage system. Whether you're an RV enthusiast, a solar energy user, or someone in need of reliable power for marine environments, this battery offers the performance, safety, and longevity that make it a top choice for demanding applications. Engineered with cutting-edge technology and built to last, the VLRV2560A delivers peace of mind knowing that your energy storage is both efficient and secure.

Key Features and Benefits

Superior Safety and Reliability

• Safety is a top priority with the VLRV2560A. This battery is equipped with an advanced Battery Management System (BMS) that constantly monitors key performance metrics such as voltage, current, and temperature. The BMS provides multiple layers of protection, including safeguards against over-voltage, under-voltage, short circuits, and temperature extremes. This level of monitoring and protection ensures that the battery operates within safe parameters at all times, reducing the risk of malfunction and extending the battery's lifespan.

Robust Durability for Long-Term Use

• Constructed with durability in mind, the VLRV2560A is designed to withstand the rigors of various applications and environments. The battery's outer casing is made from high-impact ABS plastic, which is both rugged and waterproof, earning it an IP65 rating. This means the battery is protected against dust and water, making it suitable for use in harsh outdoor environments, such as marine applications or off-grid solar setups.
• In addition to its robust construction, the battery is engineered to deliver a long operational life, significantly reducing the need for frequent replacements. This durability makes the VLRV2560A a cost-effective investment over time.

High Performance in a Compact Package

• Despite its compact size, the VLRV2560A packs a powerful punch. The battery boasts a nominal voltage of 12.8V and a nominal capacity of 200Ah, translating into a rated energy output of 2560Wh. This makes it ideal for applications requiring high energy density in a portable form factor, such as RVs and boats.
• The battery's maximum continuous discharge current of 200A ensures that you have a reliable power source even for high-demand applications. Additionally, the battery can handle short bursts of power up to 250A for 30 seconds, allowing you to meet peak energy demands without compromising the overall health of the battery.

Advanced Monitoring and Control with Bluetooth Connectivity

• In today’s connected world, having the ability to monitor your battery in real-time is a game-changer. The VLRV2560A is equipped with Bluetooth connectivity, allowing you to keep tabs on your battery's performance via the VoltGo app, available on both iOS and Android devices. This app provides detailed insights into the battery's status, including voltage, current, temperature, and state of charge (SoC). Such comprehensive monitoring helps you optimize power usage, prevent issues before they arise, and maximize the battery’s lifespan.

Seamless Integration with Victron Cerbo Equipment

• The VLRV2560A is designed to integrate seamlessly with Victron Cerbo GX and Victron Energy Ekrano GX devices. This compatibility allows the battery to be part of a sophisticated power management system, where it communicates effectively with other components via the VE.Can to CAN-bus BMS type A Cable (not included). This integration enhances the overall performance and efficiency of your energy storage system, providing you with better control and monitoring capabilities.

Inbuilt Heating System for Cold Climates

• If you frequently operate in cold climates, the VLRV2560A has you covered. The battery includes an inbuilt heating system that automatically activates in sub-zero temperatures. This feature ensures that the battery charges efficiently, even in harsh winter conditions, maintaining optimal performance regardless of the environment.

Versatile Mounting Options

• The VLRV2560A battery is designed with flexibility in mind, offering multiple mounting options to accommodate various installation environments. Whether you need to mount the battery horizontally on a flat surface or vertically against a wall, the integrated metal strips provide versatile mounting solutions. These strips can function as handles during transport or be used as brackets or locks during installation, ensuring the battery stays securely in place. This adaptability makes the VLRV2560A suitable for tight spaces, such as RV compartments, boat cabins, or utility closets in off-grid setups, where space optimization is crucial.

Parallel and Series Configurations for Expanded Capacity

• For applications that require more power or extended capacity, the VLRV2560A battery offers flexibility in system design. Multiple VLRV2560A batteries can be connected in parallel to increase the overall capacity of your energy storage system. This is particularly useful for larger RVs, boats, or solar setups that demand higher energy reserves. When connected in parallel, the batteries work together to provide a unified power source, effectively increasing the total ampere-hours (Ah) available. However, it's important to note that the VLRV2560A is not designed for series connections, which means that you cannot increase the voltage by connecting the batteries in series. This setup ensures that you can scale your power system to meet your specific energy needs without compromising the performance or safety of the batteries.

Versatile Applications

• The VLRV2560A is designed for versatility, making it suitable for a wide range of applications. Whether you're using it to power your RV on long road trips, as a backup power source in marine environments, or as part of an off-grid solar energy system, this battery is up to the task. Its rugged design and advanced features make it adaptable to various energy needs, providing reliable power wherever you need it.

Technical Specifications:

• Nominal Voltage: 12.8V
• Nominal Capacity: 200Ah
• Rated Energy: 2560Wh
• Voltage Range: 10-14V
• Cut-off Voltage: ≤10V
• Recommended Charge Current: ≤60
• Max Constant Charge Current: 150A
• Max Continuous Discharge Current: 150A
• Max Discharge Pulse Current: 250A (30 seconds pulse)
• Operating Temperature: Charge: -20°C to +45°C; Discharge: -20°C to +55°C; Storage: -20°C to +45°C
• Humidity: 5-95% RH
• Ingress Protection Rating: IP65
• Terminals: M8
• Certifications: UN38.3
• Weight: 25 kg
• Dimensions: 460 mm x 220 mm x 212 mm

Installation Steps

Unpacking and Inspection:

• Carefully unpack the battery and inspect it for any damage. Ensure all components are present and intact before proceeding with the installation.

Site Preparation:

• Choose a stable, flat surface for installation. The installation site should be clean, dry, and within the recommended temperature range (10°C to 45°C). Avoid areas exposed to direct sunlight or excessive moisture.

Battery Placement:

• Place the VLRV2560A battery in the designated location, ensuring that it is securely positioned. If using multiple batteries, secure them with appropriate brackets or straps to prevent movement during operation.

Connecting the Battery:

• Use the appropriate tools to connect the battery terminals, ensuring a secure and proper connection. Follow the manufacturer’s torque specifications for M8 terminals to avoid over-tightening.

System Integration:

• If integrating the battery with Victron Cerbo equipment, connect the battery to the system using the VE.Can to CAN-bus BMS type A Cable (not included). Ensure all connections are secure and properly configured.

Power-On and Configuration:

• Once the battery is connected, power on the system and configure the settings via the VoltGo app or Victron equipment. Monitor the battery's performance using the Bluetooth connectivity feature to ensure everything is operating correctly.

Final Checks:

• Perform a final inspection to verify that all connections are secure and that the battery is functioning as expected. Make any necessary adjustments before putting the battery into regular use.

The VoltGo VLRV2560A Lithium Iron Phosphate Battery is a powerful, reliable, and versatile energy storage solution designed to meet the needs of modern power users. Its advanced safety features, robust construction, flexible mounting options, and seamless integration capabilities make it an ideal choice for a variety of applications, from RVs and marine environments to solar energy systems. Whether you're looking for a dependable power source for your next adventure or a long-lasting battery to support your energy system, the VLRV2560A offers the performance and peace of mind you need. Invest in the VoltGo VLRV2560A today and experience the benefits of cutting-edge energy storage technology.
